．小巧精緻
．方便攜帶
．待機時間長
．聲音清晰響亮
．省電功能
．低電量警報
．模擬數字亞音頻
．中英文語音報號
．手電筒功能
．發射限時
．電腦讀寫頻密碼
．技術指標Specifications
．頻率範圍 Frequency Range 467.5125-467.6750MHz
．額定電壓Operating Voltage DC3.7V (Li-ion battery)
．記憶頻道Memory Channels 14 Channels
．天線阻抗Antenna Impedance 50Ω
．頻率步進Frequency Spacing 12.5/25 KHz
．電池容量Battery 1300mAh
．工作溫度Working Temperature -10°C ∼ +50°C
．尺寸Dimensions 90×45×25 mm
．重量Weight 115g
．發射部分Transmitting
．輸出功率Output Power 1W
．調制方式Modulation Mode 16KΦF3E/11KΦF3E
．最大偏差Maximum Deviation ≤5.0KHz(W)/ ≤2.5KHz(N)
．雜散功率Stray Power ≤7.5uW
．調制失真Modulation Distortion ≤5%
．調制靈敏度Modulation Sensitivity 8-12mV
．接收部分Receiver
．靈敏度Sensitivity -122dBm(12dB SINAD)
．鄰道功率Adjacent Channel Power ≤-65dB(W) / ≤-55dB(N)
．音頻失真 Audio Distortion ≤10%
．雜波抑制Spurious Response Rejection ≥65dB
．音頻輸出功率Audio Power Output 1W
